Vehicle Information
Battery Capacity % guaranteed under warranty:70
Battery Capacity in kWh:13.6
Battery Charging Scenario 1 - Charge Time (Mins):352
Battery Charging Scenario 1 - Percentage Change:0-100
Battery Charging Scenario 1 - Power Supply - kW:2.3
Battery Charging Scenario 2 - Charge Time (Mins):116
Battery Charging Scenario 2 - Percentage Change:0-100
Battery Charging Scenario 2 - Power Supply - kW:7
Battery Type:Lithium-ion
Charging Port Location:Right Side Rear
Coupler/Connector Type:CCS Type 2
Maximum Charging Rate - kW:7
Standard manufacturers Battery warranty - Mileage:60000
Standard manufacturers Battery warranty - Years:3
Usable Battery Capacity:Not Available
WLTP - EC AC Weighted (kWh/100km) - Comb:12.8
WLTP - EC AC Weighted (miles/kWh) - Comb:4.9
WLTP - Equivalent AER (km) - City:111
WLTP - Equivalent AER (km) - Comb:86
WLTP - Equivalent AER (miles) - City:69
WLTP - Equivalent AER (miles) - Comb:53.4
CO:0.153
HC:0.014
HC+NOx:Not Available
Noise Level dB(A):65
NOx:0.004
Particles:0.0002
Standard Euro Emissions:EURO 6
WLTP - CO2 Weighted (g/km) - Comb:12
WLTP - CO2 Weighted (g/km) - Comb - TEH:14
WLTP - CO2 Weighted (g/km) - Comb - TEL:12
Camshaft:DOHC
Catalytic Convertor:Yes
CC:1987
Compression Ratio:14.0:1
Cylinder Layout:IN-LINE
Cylinders:4
Cylinders - Bore (mm):80.5
Cylinders - Stroke (mm):97.6
Engine Code:M20A-FXS
Engine Layout:FRONT TRANSVERSE
Fuel Delivery:MULTI POINT FUEL INJECTION
Gears:1 SPEED
Number of Valves:16
Transmission:AUTO
EC Directive 1999/100/EC Applies:No
WLTP - FC Weighted (l/100km) - Comb:0.5
WLTP - FC Weighted (l/100km) - Comb - TEH:0.6
WLTP - FC Weighted (l/100km) - Comb - TEL:0.5
WLTP - FC Weighted (mpg) - Comb:564.9
WLTP - FC Weighted (mpg) - Comb - TEH:470.8
WLTP - FC Weighted (mpg) - Comb - TEL:565
Alternative Fuel Qualifying:Yes
Badge Engine CC:2.0
Badge Power:223
Based On ID:Not Available
Coin Description:PHEV
Coin Series:Design
Generation Mark:5
Insurance Group 1 - 50 Effective January 07:31A
Did at least one aspect of this vehicle's safety give cause for concern?:No
Special Edition:No
Special Order:No
Vehicle Homologation Class:M1
0 to 62 mph (secs):6.8
Engine Power - BHP:223
Engine Power - KW:164
Engine Power - RPM:6000
Engine Torque - LBS.FT:140
Engine Torque - MKG:19.4
Engine Torque - NM:190
Engine Torque - RPM:4400
Top Speed:110
Emissions Test Cycle:WLTP
RDE Certification Level:RDE 2
Alloys?:Yes
Space Saver?:No
Tyre Size Front:195/60 R17
Tyre Size Rear:195/60 R17
Tyre Size Spare:TYRE REPAIR KIT
Wheel Style:5 SPOKE
Wheel Type:17" ALLOY
Height:1420
Height (including roof rails):Not Available
Length:4599
Wheelbase:2750
Width:1782
Fuel Tank Capacity (Litres):40
Gross Vehicle Weight:1995
Max. Loading Weight:450
Minimum Kerbweight:1545
No. of Seats:5
Battery Capacity % guaranteed under warranty:70
Battery Capacity in kWh:13.6
Battery Charging Scenario 1 - Charge Time (Mins):352
Battery Charging Scenario 1 - Percentage Change:0-100
Battery Charging Scenario 1 - Power Supply - kW:2.3
Battery Charging Scenario 2 - Charge Time (Mins):116
Battery Charging Scenario 2 - Percentage Change:0-100
Battery Charging Scenario 2 - Power Supply - kW:7
Battery Type:Lithium-ion
Charging Port Location:Right Side Rear
Coupler/Connector Type:CCS Type 2
Maximum Charging Rate - kW:7
Standard manufacturers Battery warranty - Mileage:60000
Standard manufacturers Battery warranty - Years:3
Usable Battery Capacity:Not Available
WLTP - EC AC Weighted (kWh/100km) - Comb:12.8
WLTP - EC AC Weighted (miles/kWh) - Comb:4.9
WLTP - Equivalent AER (km) - City:111
WLTP - Equivalent AER (km) - Comb:86
WLTP - Equivalent AER (miles) - City:69
WLTP - Equivalent AER (miles) - Comb:53.4
CO:0.153
HC:0.014
HC+NOx:Not Available
Noise Level dB(A):65
NOx:0.004
Particles:0.0002
Standard Euro Emissions:EURO 6
WLTP - CO2 Weighted (g/km) - Comb:12
WLTP - CO2 Weighted (g/km) - Comb - TEH:14
WLTP - CO2 Weighted (g/km) - Comb - TEL:12
Camshaft:DOHC
Catalytic Convertor:Yes
CC:1987
Compression Ratio:14.0:1
Cylinder Layout:IN-LINE
Cylinders:4
Cylinders - Bore (mm):80.5
Cylinders - Stroke (mm):97.6
Engine Code:M20A-FXS
Engine Layout:FRONT TRANSVERSE
Fuel Delivery:MULTI POINT FUEL INJECTION
Gears:1 SPEED
Number of Valves:16
Transmission:AUTO
EC Directive 1999/100/EC Applies:No
WLTP - FC Weighted (l/100km) - Comb:0.5
WLTP - FC Weighted (l/100km) - Comb - TEH:0.6
WLTP - FC Weighted (l/100km) - Comb - TEL:0.5
WLTP - FC Weighted (mpg) - Comb:564.9
WLTP - FC Weighted (mpg) - Comb - TEH:470.8
WLTP - FC Weighted (mpg) - Comb - TEL:565
Alternative Fuel Qualifying:Yes
Badge Engine CC:2.0
Badge Power:223
Based On ID:Not Available
Coin Description:PHEV
Coin Series:Design
Generation Mark:5
Insurance Group 1 - 50 Effective January 07:31A
Did at least one aspect of this vehicle's safety give cause for concern?:No
Special Edition:No
Special Order:No
Vehicle Homologation Class:M1
0 to 62 mph (secs):6.8
Engine Power - BHP:223
Engine Power - KW:164
Engine Power - RPM:6000
Engine Torque - LBS.FT:140
Engine Torque - MKG:19.4
Engine Torque - NM:190
Engine Torque - RPM:4400
Top Speed:110
Emissions Test Cycle:WLTP
RDE Certification Level:RDE 2
Alloys?:Yes
Space Saver?:No
Tyre Size Front:195/60 R17
Tyre Size Rear:195/60 R17
Tyre Size Spare:TYRE REPAIR KIT
Wheel Style:5 SPOKE
Wheel Type:17" ALLOY
Height:1420
Height (including roof rails):Not Available
Length:4599
Wheelbase:2750
Width:1782
Fuel Tank Capacity (Litres):40
Gross Vehicle Weight:1995
Max. Loading Weight:450
Minimum Kerbweight:1545
No. of Seats:5
2.0 PHEV Design 5dr CVT
